Cloth Wire

Cloth wire is also commonly known as insulated wire, is the most commonly used soft and hard wire for home decoration, like BV, BVR, RYJ, RVS, these are the types of cloth wire for home use.

Electric wire is divided into electromagnetic wire and general insulated wire by use, insulated wire is also known as cloth wire. Insulated wire (cloth wire) is the wire covered with insulation, including a variety of connection lines, installation lines. The cloth wire products of Gooda Cable are suitable for power installations, fixed wiring and flexible connection of electrical appliances with rated voltage 450/750V and below respectively. Flame-retardant, fire-resistant, halogen-free and low-smoke flame-retardant, armored cables meet the corresponding flame-retardant, fire-resistant, halogen-free and low-smoke flame-retardant performance requirements respectively

The use of cloth wire

Cloth wire can be used in a wide range of applications, including street lighting, fire-fighting, home furnishing and other household appliances, such as washing machines, electric water heaters, fixed sockets, central air conditioners, microwave ovens and so on.

Although cloth wire can be used for many household appliances, but not every specification can be applied to these appliances, some high-power appliances should match the specifications of larger cloth wire, otherwise it is easy to cause a short circuit or heat; commonly used specifications are 1.5 square, 2.5 square, 4 square, 6 square, 10 square, 16 square these kinds of. And then there are 25 square, 35 square, 50 square, 70 square, etc., relatively these home furnishings with less.

Common cloth wire model specifications

BVR: copper core polyethylene insulation layer of flexible cable wire, alias soft cable wire, secondary wire.

RVS: copper-core polyethylene insulation stranded type coupling with flexible cable wire, alias five twisted pairs, soft wire, fire safety wire.

RVB/RVVB: copper core polyethylene insulation layer without wire sheath/with wire sheath flat copper wire, alias red and black strip, black and red (parallel surface) wire.

RV/BV: copper core polyethylene insulation layer single-core soft/hard cable wire, alias single-root cable wire, cloth wire.

RYJ/BYJ: copper-core polyolefin insulation layer environmental protection soft/hard cloth wire, alias high-density polyethylene cable wire, environmental protection cable wire, cloth wire.

The main uses of different specifications of cloth and wire

1, 1.5mm ² wire is generally home furnishing basic lighting fixture line all can be used, that is, more basic. Some cable line plug, some small electrical products are available 1.5mm² wire.

2, 2.5 mm ² wire is relatively large, now all copper heart wire accounted for the majority of the natural old cable wire may be aluminum cable, if the new copper heart wire 2.5 mm ² can promote most of the basic electrical products, like rice cookers, induction stoves can be used.

3, 4mm² wire is used more frequently, like air conditioning, domestic water heaters, bathroom lights, heating, home air system, which are all power household appliances, must be used 4mm² wire.

4, 6mm² wire is generally the wire into the home, as if every home base is outdoor which distribution cabinet is all 6mm² cable wire, this is also the larger square wire.
